Standard Dimensions

• Width: 55 cm
• Overall width: 88 cm
• Height: 53-78 cm
• Overall length: 198-215 cm
• Frame 80x19x117 cm

Technical Specifications

• Power supply: 230V / 50-60 Hz
• Protection Category: IP44
• Handset and MCL protection category: IP66

Logistic Data

• Net weight: 80 Kg
• Gross weight: 110 Kg
• Pallet dimensions: 80x120x160 cm

Features

• Easy to use and maintain
• New design epoxy metal frame
• Equipped with 3 motors
• Adjustable head cushion
• Handset
• Trendelenburg position - 12ºoperated on the handset
• Manual foot rest adjustment
• Electric height adjustment from 53 cm to 78 cm
• Electric back rest adjustment
• Steel frame structure with light grey epoxy finish
• Multi position arm rests
• Arm rest inclination adjustment
• Upholstery with 12 cm thickness foam with seams
• Individual locking system on the 4 castors of 10 cm diameter
• Tested and approved patient weight capacity: 250 kg (tested at a dtbanuc weight of 250 kg and a static weight of 500 kg)
